    IL12000 Scissor Lift Table

    £ 29,762.00 excl. VAT OutOfStock
    £ 35,714.00 Incl. VAT

    High quality lift table 12000 kg with platform size 3500 mm x 2000 mm, lifting to 2570 mm

    Customization options are available, allowing you to tailor the platform to your specific needs with dimensions ranging from 3000 to 3800 mm in length and 1600 to 2000 mm in width.

    IN PRODUCTION

    Travel 1800 mm
    Closed height 770 mm
    Total height 2570 mm
    Platform length 3500 mm
    Platform width 2000 mm
    Capacity 12000 kg
    Lifting Time 0 sec

    STANDARD SAFETY FEATURES INCLUDED

    • Hose burst valve to secure table from descending in case of breakage/leakage of hydraulic hoses
    • Control box and electrical components designed for safety and durability
    • Safety bar underneath platform will stop descent if obstructed
    • Over-pressure valve to safeguard hydraulics and motor from overload
    • Safe maintenance features
    • Includes hand controller with up, down, and, emergency stop functions

    HIGHEST QUALITY STANDARDS ON ALL COMPONENTS

    • Unique control box with excellent performance, developed and produced locally next to our production facilities
    • Top performing hydraulic components – each one carefully selected for durability and safe performance
    • State of the art electrical components and wiring. Designed to last
    • Quality controlled – every single table leaving Sax Lift has passed a thorough quality protocol and check procedure

    STANDARD SETUP

    • Power supply 3-phase, 400V N + PE, 50Hz, 13 Amp is standard
    • CEE Power plug
    • IP54 rated
    • Plug and Play

    This product is in compliance with EN 1570-1
